TC-P3S06
68.01 azn
Tiandy
60 W
5 Port
PoE
100mb/s
Yeni
Haqqında
TC-P3S06 4PORT POE 2UPLINK 10/100MB SWITCH TIANDY
| PoE gücü | 60 W |
| Port sayı | 5 Port |
| PoE | PoE |
| Port sürəti | 100mb/s |
Ətraflı
| I/O Interface | |
| Power | AC INPUT (100-240V) |
| Ethernet | 4*10/100Mbps PoE Ports ,2*10/100Mbps RJ45 Uplink Ports |
| Performance | |
| Bandwidth | 1.2 Gbps |
| Throughput | 0.8928Mpps |
| Packet Buffer | 448K |
| MAC Address | 1K |
| Transfer Mode | Store and forward |
| Standard | |
| Network Protocol | EEE802.3 (10Base-T) IEEE802.3u (100Base-TX) |
| PoE Protocol | IEEE802.3af (15.4W) IEEE802.3at (30W) POE port output voltage: DC 52V POE power supply core: 1/2+; 3/6- |
| Industrial Standard | EMS: EN61000-4-2 (ESD), EN61000-4-5 (Surge) |
| Network Medium | 10Base-T: Cat3, 4, 5 or above UTP/STP (≤100m) 100Base-TX: Cat5 or above UTP/STP (≤100m) |
| Function | |
| LED Indicators | PWR (Power Supply), Mode (DIP), 1-6 Green (Link & Data), POE Max (Power) |
| PWR | On: Powered on Off: Powered off |
| POE LED Buttons | Dual color light selection: default green (link data), switch yellow light (POE) |
| DIP Switch | |
| VLAN | VLAN: (Port Isolation Mode). In this mode, the PoE ports (1-4) of the switch cannot communicate with each other and can only communicate with the Uplink port (5, 6). The port AI mode (PoE Watchdog) is turned on. |
| Default | Default: (Normal Mode). All Ports can communicate with each other, the transmission rate is 10/100Mbps adaptive; The port AI mode is disabled |
| Extend | Extend: (Link Extension Mode). 1-4 ports force 10M, link 220M. The port AI mode (PoE Watchdog) is turned on. |
| Environment | |
| Working Environment | Working Temperature: -10~50℃ Storage Temperature: -40~70℃ Working Humidity: 10%~90%, non-condensing Storage Temperature: 5%~95%, non-condensing |
| Physical Specifications | |
| Dimension | Product Dimensions: 200*118*44mm Package Dimensions: 245*190*60mm Product N.W: 0.54KG Product G.W: 0.88KG |
| Packing Info | Carton Dimensions: 520*320*400mm Packing Quantity: 20PCS Packing Weight: 18.6KG |
| Power Voltage | Input Voltage: AC 100-240V Power Supply: 52V /1.25A |
| Power | Mainboard power: maximum 10W POE power: maximum 55W |
